Machine Photos & Specification
| Compression Force |
40ton |
60ton |
80ton |
| Bale Size (WxHxL) |
720x720x(500-1300)mm |
750x850x(500-1600)mm |
1100x800x(500-1800)mm |
| Feed Opening Size (LxW) |
1000x720mm |
1200x750mm |
1500x800mm |
| Bale Line |
4 lines |
4 lines |
4 lines |
| Bale Weight |
200-400kg |
300-500kg |
400-600kg |
| Power |
11Kw/15Hp |
15Kw/20Hp |
22Kw/30Hp |
| Capacity |
1-2ton/hour |
2-3ton/hour |
4-5ton/hour |
| Out Bale Way |
Continuously push bale |
Continuously push bale |
Continuously push bale |
| Machine Size (LxWxH) |
4900x1750x1950mm |
5850x1880x2100mm |
6720x2100x2300mm |
Machine Description
✓
Adopting the left and right shrinking method through the oil cylinder automatic and manual tightening and relaxation easy to adjust.
✓
Left-right compressing and pushing bale out, the length of bale can be adjusted, pushing out bale continuously to improve work efficiency.
✓
PLC program control electric button control simple operation with feeding detection and automatic compression.
✓
The baling length can be set and there are bundling reminders and other devices.
✓
The size and voltage of the bale can be customized according to the reasonable requirements of the customer. The weight of the bale is different for different packaging materials.
✓
Three-phase voltage safety interlock simple operation can be equipped with air pipe and conveyor feeding material with higher efficiency.
Why Choose Us?
● We take pride in our ability to produce top-quality Semi Automatic Baler products at affordable prices.
● After years of unremitting efforts and pursuits, adhering to the corporate tenet of 'Quality, Speed, Service', we provide excellent services.
● We have a wide range of Semi Automatic Baler products ensuring that customers can find what they need.
● We focus on improving processing technology and research to strengthen technological content and quality awareness.
● Our factory has a proven track record of producing reliable and durable Semi Automatic Baler products.
● We provide high-quality cargo tracking services to greatly improve efficiency for customers.
● Our products are backed by a comprehensive warranty and maintenance program.
● Our experienced technicians ensure each product meets the highest quality standards.
It is widely used for compression and baling packaging of carton, printing paper mill, food, garbage recycling, and other industries.
| Compression Force |
100ton |
120ton |
150ton |
| Bale Size (WxHxL) |
1100x1100x(500-1800)mm |
1100x1200x(500-2000)mm |
1100x1200x(500-2100)mm |
| Feed Opening (LxW) |
1800x1100mm |
2000x1100mm |
2200x1100mm |
| Bale Line |
5 lines |
5 lines |
5 lines |
| Bale Weight |
700-1000kg |
800-1050kg |
900-1300kg |
| Power |
30Kw/40Hp |
37Kw/50Hp |
45Kw/61Hp |
| Capacity |
5-7ton/hour |
6-8ton/hour |
6-8ton/hour |
| Out Bale Way |
Continuously push bale |
Continuously push bale |
Continuously push bale |
| Machine Size |
7750x2400x2400mm |
8800x2400x2550mm |
9300x2500x2600mm |
Frequently Asked Questions
Q1: What materials are suitable for this semi-automatic baler?
A: It is widely used for cardboard, carton scraps, printing paper, food packaging, and various garbage recycling materials.
Q2: Can the bale length be adjusted?
A: Yes, the baling length can be set and adjusted according to your specific requirements through the control system.
Q3: What kind of control system does the machine use?
A: The machine utilizes a PLC program control combined with electric buttons for simple, reliable operation.
Q4: Is the voltage customizable for different countries?
A: Yes, the voltage and frequency can be customized based on the customer's local power supply requirements.
Q5: How does the "Continuous Push" method work?
A: The machine compresses and pushes bales out continuously from the side, which significantly improves work efficiency compared to single-cycle balers.
Q6: What safety features are included in the design?
A: It features a three-phase voltage safety interlock and feeding detection to ensure safe and efficient operation for the users.
