📋 Specification
| Technical Parameters |
Model 2300 |
Model 2500 |
| Max. Slitting width | 2000 mm | 2000 mm |
| Min. Slitting width | 140 mm | 140 mm |
| Min. Scoring width | 140 mm | 140 mm |
| Weight | 3200 kg | 3500 kg |
| Install Power | 16 kw | 17 kw |
| Running Power | 13.5 kw | 14.5 kw |
| Change Order Time | 20-30 s | 20-30 s |
| Qty Of Order Storage | 9999 | 9999 |
| Max. Speed | 200 m/min | 200 m/min |
| Blade (mm) | Φ 200 × 122 × 1.2 | Φ 200 × 122 × 1.2 |
| Diameter of Scoring Wheel | 156 mm | 156 mm |
| Working Pressure | 0.6-0.8 mpa | 0.6-0.8 mpa |
Machine dimension (mm)
(Don't include workbench) | 3500 × 1350 × 2050 | 3700 × 1350 × 2050 |
| Blade & Scoring Composed Type | 4 cuts 6 lines/ 5 cuts 8 lines | 5 cuts 8 lines/ 6 cuts 10 lines |
⚙️ Machine Description
🌟 Why Choose Us?
✓ We are constantly striving to improve our Slitting Scorer Machine products and services to better serve our customers' needs.
✓ We insist on professionalism and efficiency, technological innovation, and are committed to providing services to customers.
✓ Our factory has been in the business for many years, and we have developed a reputation for excellence in the industry.
✓ We will continue to build on our achievements, forge ahead and innovate to make new contributions to the industry.
✓ Our knowledgeable customer service team is always available to assist with any technical questions.
✓ We uphold the enterprise spirit of honesty, dedication, efficiency and innovation.
🚀 Core Features & Advantages
● Servo drive front feed for high-speed precision.
● Input all orders for per shift at once to save work efficiency.
● PLC control with touch screen for accurate positioning and easy operation.
● Pneumatic control for blade and scorer with automatic grinding functionality.
● Slitting blade adopts tungsten alloy for long working life and neat edges.
● Creaser includes pre-creaser and fine-creaser for beautiful creasing lines without seam breakage.
● Transmission adopts imported synchronous belt for steady, low-noise operation.
● Linear guideway and ballscrew structure for high precision positioning.
❓ Frequently Asked Questions
Q1: How long does it take to change an order?
A: The machine is designed for high efficiency, with an order change time of only 20-30 seconds.
Q2: What is the maximum order storage capacity of the PLC system?
A: The system can store up to 9999 orders, making it ideal for users with diverse and frequent order changes.
Q3: What material is used for the slitting blades?
A: We use high-quality tungsten alloy blades, which provide a long working life and ensure the slitting edge is neat without burrs.
Q4: Does the machine prevent cardboard from breaking during creasing?
A: Yes, our creasing system includes both a pre-creaser and a fine-creaser to ensure no seam breakage and easy bending.
Q5: What is the maximum running speed of the machine?
A: The Slitting Scorer Machine can reach a maximum working speed of 200 meters per minute.
Q6: Is the machine easy for operators to use?
A: Absolutely. It features a humanized touch screen interface and PLC control for precise, simple, and intuitive operation.
