Specification
| Model |
LQJPW40F |
LQJPW60F |
LQJPW80F |
LQJPW100F |
| Compression force |
40Ton |
60Ton |
80Ton |
100Ton |
| Bale size (WxHxL) |
720x720 x(500-1300)mm |
750*850 *(500-1600) |
1100*800 *(500-1800) |
1100*1100 *(500-1800) |
| Feed opening size (LxW) |
1000x720mm |
1200x750mm |
1500x800mm |
1800x1100mm |
| Bale line |
4 lines |
4 lines |
4 lines |
5 lines |
| Bale weight |
200-400kg |
300-500kg |
400-600kg |
700-1000kg |
| Power |
11Kw/15Hp |
15Kw/20Hp |
22Kw/30Hp |
30Kw/40Hp |
| Capacity |
1-2Ton/Hr |
2-3Ton/Hr |
4-5Ton/Hr |
5-7Ton/Hr |
| Out bale way |
Continuously push bale |
Continuously push bale |
Continuously push bale |
Continuously push bale |
| Machine size (LxWxH) |
4900x1750x1950mm |
5850x1880x2100mm |
6720x2100x2300mm |
7750x2400x2400mm |
Machine Description
✓
Versatile Application
It is widely used for compression and baling packaging carton printing paper mill food garbage recycling and other industries.
✓
Manual Adjustment
Adopting the left and right shrinking method through the rod manual tightening and relaxation, easy to adjust.
✓
High Efficiency
Left-right compressing and pushing bale out; the length of the bale can be adjusted, pushing out bales continuously to improve work efficiency.
✓
PLC Control
PLC program control with electric button operation is simple, featuring feeding detection and automatic compression.
✓
Customizable Length
The baling length can be set, and there are bundling reminders and other integrated devices.
✓
Flexible Specifications
The size and voltage of the bale can be customized according to requirements. The weight of the bale varies for different materials.
✓
Safety Interlock
Three-phase voltage safety interlock for simple operation; can be equipped with air pipes and conveyor feeding for higher efficiency.
Why Choose Us?
★
Transparent pricing policy ensures customers get the best prices for Multi Layer Corrugated Board Production Line products.
★
We win customer trust with high-quality Semi Automatic Horizontal Baler units and sincere service.
★
Great reputation for delivering reliable and efficient production line products and services.
★
Standardized product quality system with a rapid warehousing and logistics response mechanism.
★
Excellent customer service and support to ensure full satisfaction with all equipment.
★
Strict management, advanced technology, and stable quality rooted in years of industry experience.
Frequently Asked Questions
What materials can this horizontal baler process?
The machine is widely used for packaging carton, printing paper, food waste, and other materials in recycling industries.
Is the bale length adjustable?
Yes, the bale length can be set through the PLC control system, and the machine supports continuous pushing for higher efficiency.
What is the range of compression force available?
We offer models with compression forces ranging from 40 Ton (LQJPW40F) up to 100 Ton (LQJPW100F).
Does the machine support automatic operation?
Yes, it features a PLC program control with electric buttons, feeding detection, and automatic compression capabilities.
Can the voltage and bale size be customized?
Absolutely. Both the size and voltage can be customized according to the specific and reasonable requirements of the customer.
What are the safety features of this equipment?
The machine is equipped with a three-phase voltage safety interlock system to ensure simple and safe operation.
